When you hold two quotes for anti reflective sapphire crystal coating side by side, the coating line itself tells you the least. What decides whether the comparison is fair is everything around it: which surfaces are coated, what layer stack is quoted, what evidence backs the claim, what acceptance test applies, and who owns rework if a batch fails. Use a structured framework to normalise both quotes before judging either price.
Why price-per-crystal comparison fails for AR coating
A quote line that reads "AR coating, double-sided" can describe materially different scopes. One supplier may be quoting a single-layer coating on the outer surface only; another may include a multi-layer stack on both surfaces plus an anti-smudge top coat. One may include coating adhesion and scratch testing as an acceptance gate; another may treat testing as an extra. Unless you equalise these variables, you are comparing two different products that happen to share a name.
The fix is procedural, not technical. You do not need to become a thin-film engineer. You need a checklist that forces both suppliers to answer the same questions in the same units, so the commercial comparison happens on matched ground.
The CLEAR framework for comparing coating quotes
Use CLEAR to structure the comparison:
- C — Coating scope. Which surfaces are coated, what layer count or stack design is quoted, and whether any top coat is included.
- L — Layer data. What the supplier will document about the coating design: layer count per surface, materials family if disclosed, and the reflectance or transmission target the coating is built against.
- E — Evidence. What measurement the supplier will provide — measurement method, instrument type, sample basis, and whether results are per-batch or per-development run only.
- A — Acceptance terms. The pass/fail criteria written into the quote: reflectance window, adhesion test, abrasion test, cosmetic inspection standard, and sampling plan.
- R — Responsibility split. Who bears cost and delay if a batch fails acceptance, if the coating cracks in assembly, or if the design must be revised after first articles.
Work through each letter for both quotes. Where a supplier has not stated something, do not fill the gap with an assumption — send it back as a written question. An unspecified item is not a small item; it is a future dispute.
Line-by-line quote comparison table
| Line item | What to demand from both suppliers | Why it changes the comparison |
|---|---|---|
| Coated surfaces | Written confirmation: outer, inner, or both | Two-surface coating involves more process steps than one; a single-surface quote is not comparable |
| Layer stack description | Layer count per surface and any top coat | Determines durability and optical performance class of the quoted coating |
| Reflectance/transmission target | A numeric target band with measurement wavelength and angle, stated in writing | Converts "good AR coating" into a criterion you can test against |
| Measurement evidence | Method, instrument class, sample basis, and which lots get measured | Distinguishes a development-run measurement from a per-batch quality gate |
| Adhesion and abrasion criteria | Named test methods and pass conditions | Defines what happens when a coating fails in the field, before it happens |
| Cosmetic inspection standard | Inspection distance, lighting, and accepted defect definitions | Prevents disagreement over visible marks after delivery |
| Substrate inclusion | Whether the sapphire crystal itself is in the same quote or coated from your stock | A coating-only quote and a crystal-plus-coating quote are different purchases |
| Rework and rejection responsibility | Who pays if a lot fails acceptance | Shifts real cost more than the headline price does |
| Revision ownership | Cost of changing the coating design after first articles | Protects you if optical targets need tuning |
| Sample and pilot policy | Current sample policy, costs and timing — confirm directly with each supplier | These terms vary and must be verified, not assumed |
Fill one column per supplier. Any row left blank by a supplier is a question, not a concession.
Approval questions to send both suppliers
Before you sign either quote, get written answers to these:
- Which surfaces receive the anti reflective coating, and how many layers are applied per surface?
- What reflectance or transmission target does the coating meet, at what wavelength and angle, and how will you measure and report it?
- Which adhesion, abrasion and environmental tests do you apply, and what are the pass conditions?
- What inspection standard governs cosmetic defects, and at what viewing distance and lighting?
- Is the sapphire crystal substrate included in this quote, or is coating applied to customer-supplied parts?
- What documentation accompanies each batch — measurement report, inspection record, or certificate?
- If a lot fails your own acceptance criteria, who absorbs the rework and the schedule impact?
- If the coating design needs revision after first articles, how is that change scoped and charged?
- What are your current sample, pilot-lot and production policies — MOQ, pricing, lead times and shipping terms — stated in writing for this project?
- Which coating design decisions do you need fixed before tooling begins, and which can be adjusted later?
Question 9 matters more than it looks. Sample policy, cost structure, lead time and capacity are project-specific and change over time; no responsible comparison assumes them. Ask both suppliers the same question and compare the answers you actually receive.
Red flags that pause the comparison
- The quote references "standard coating" without stating surfaces, layer count or a measurable target.
- Quality evidence is described but not defined — no method, no instrument, no sampling basis.
- Acceptance testing exists in conversation but not in the quotation document.
- Rework responsibility is silent on failure scenarios.
- Sample and pilot terms are described verbally rather than in writing.
Any of these means the quote is not yet comparable. Close the gaps in writing first; the price comparison becomes meaningful only afterwards.
Frequently asked questions
Is double-sided coating the better specification for a watch crystal? It depends on the design goal. Coating both surfaces reduces internal reflections further, but adds process steps and cost. Define the optical target first, then let the layer count follow the target — not the reverse.
How do I compare quotes when one supplier includes the crystal and the other quotes coating only? Split them into two scopes. Ask the coating-only supplier to quote on the same part definition, or ask the integrated supplier to unbundle the crystal line. Compare like scopes only.
What coating evidence should I require before approving tooling? At minimum: the stated reflectance or transmission target with measurement conditions, the test methods for adhesion and abrasion, and confirmation of what will be reported per batch versus per development run.
Can I use one supplier's specification to challenge another's price? Yes, if the specification is written and measurable. Handing both suppliers the same coating specification — surfaces, layer intent, target band, acceptance tests — converts an opaque price into a comparable one.
How do I handle coating design changes after first articles? Agree the mechanism before signing: who initiates, how the change is scoped, and how cost and schedule impact is allocated. Document it in the quote, not in memory.
Next step: confirm your coating specification
The cleanest way to de-risk an AR coating quote is to fix the specification before requesting numbers. Send JadeZone Sapphire your drawing or target optical performance, and we will work with you to confirm a coating specification — surfaces, layer intent, measurable targets and acceptance criteria — that any quote can be compared against.
Alternatively, start with the ten approval questions above as a one-page checklist. Send them to every supplier on your list, including us, and compare the written answers. That checklist alone will tell you a great deal about who you are buying from.
